Equipment List

The YachtThe Builder

LOA 62 Feet
Beam 19 Ft
Displacement 61 Gross Tons
Draft 5'6"
Cruising Speed 14 knots
Engines Twin Lugger 6140's 700 HP each
Generator Two Northern Lights 25 kw with soundshields
Wet Exhaust Triple combo SEP Mufflers (Quietest made)
Transmission Twin disc
Bow Thruster Wesmar Hydraulic 25HP
Fuel 2000 gallons, 2 tanks
Fuel filters Racor 75/1000 Max on each main
  Racor 50/1000 Max on Generator
Lube oil transfer system Reverso
Portlights Five commercial grade ¾ inch glass, aluminum dead light cover
Watertight doors Two Commercial grade, 6 dogs each
Water Capacity 1400 gallons
Power Inverter Trace 3 KW
Heat 220V Boat Safe, Stainless Steel, located throughout
Water Maker Village Marine commercial 1200 GPD watermaker
Watertight Compartments Seven
Sound & Thermal Insulation Two to three inches sprayed closed cell foam throughout (excluding engine room)
  1 ½ - 3 inch foam with vinyl barrier throughout engine room
Electronics A full suite of electronics including:
  Simrad CA54
  6KW 72NM Radar with 6 ft open array
  Chart Plotter with SDGPS
  Dual Frequency 1000 Watt Echo Sounder with commercial transducer
  Simrad CE32 Chart Plotter and Echo Sounder
  Furuno 1621 MKII 16 mile radar
  Three VHF's
  Satellite Phone
  Cellular Phone
Anchor Winch Commercial hydraulic
Pot Puller Commercial hydraulic
Davit Winch Commercial hydraulic
Crane 2000# Marquipt
Bilge/washdown pump Commmercial hydraulic
Dinghy 3.8 Meter NAIAD Inflatable with 25 HP Honda 4 stroke motor
Life Raft Two 8 person inflatables
Premium fishing gear
Pump Honda Portable Gas Driven 2 inch dewatering pump
Flooring Marine Deck 2000 Cork Flooring & Carpet
Fighting Chair Nautical Design 130# Tournament Chair
